Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model

Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model
Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model

Large Image :  Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: ST
Payment & Shipping Terms:
Minimum Order Quantity: 2sets
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100pcs/day
Detailed Product Description
Brand: DONGHUAN Model: ST12
Rated Load: 12KN Hook Groove Length: 120MM
Name: Conductor Lifter Type: Overhead Transmission Line Tools
High Light:

tower climbing equipment

,

tower safety equipment

Rated Load 12KN ST Model Conductor Lifter Overhead Transmission Line Tools



Quick Information:

Brand: Dong Huan Brand

Model: ST12

Rated Load:12KN

Hook Groove length(mm): 120mm

Type: Transmission line stringing tools

Specification:

Model Rated load(KN) Hook groove length(MM)
ST12 12 120
ST25 25 160
ST40 40 250



Advantages:

1.Nylon backing for effective protection of the wire sheath

2.Use twist-free wire rope for better bearing and no bending

3.The claws are made of alloy steel with high strength and no deformation



Multiple Fission Conductor Lifter Other products:

Model Rated load (KN) Hook groove length (mm) Weight (kg)
ST25-2 2X12 120 13
ST50-2 2X25 160 25
ST80-2 2X40 250 40
ST36-3 3X12 120 21
ST75-3 3X25 160 35
ST120-3 3X40 250 60
ST48-4 4X12 120 35
ST100-4 4X25 160 60
ST160-4 4X40 250 90
ST150-6 6X25 160 70
ST240-6 6X40 250 110
ST200-8 8X25 160 120
ST320-8 8X40 250 160



Lifting wire for two bundle conductors or four bundled conductors or sex bundled conductor or eight bundled conductors.

Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model 0Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model 1Overhead Transmission Line Stringing Tools 12KN Conductor Lifter ST Model 2
