Tubular Tripod Aluminum Alloy Gin Pole Tower Gin Pole Derrick Gin Pole

Tubular Tripod Aluminum Alloy Gin Pole Tower Gin Pole Derrick Gin Pole
Tubular Tripod Aluminum Alloy Gin Pole Tower Gin Pole Derrick Gin Pole

Large Image :  Tubular Tripod Aluminum Alloy Gin Pole Tower Gin Pole Derrick Gin Pole

Product Details:
Place of Origin: NINGBO
Brand Name: Linkai
Certification: ISO CE
Model Number: LBGS
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Get the latest
Packaging Details: Customized
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 5000pcs/month
Contact Now
Detailed Product Description
Type: Derrick Gin Pole Model: LBGS
Material: Aluminum Alloy Max Output Force: 5kn
Weight (kg/m): 8 Certificaiton: ISO CE
High Light:

Tripod Aluminum Alloy Gin Pole

,

Tubular Tower Gin Pole

,

Derrick Tower Erection Pole

Tubular Tripod Aluminum Alloy Gin Pole Tower Gin Pole Derrick Gin Pole



Tubular tripod aluminum alloy gin pole with manual winch is used for setting up a small gin pole or hosting small components in line construction.

Tubular tripod aluminum alloy gin pole with manual winch



Ordernumber
Model
Footspan (m)
Allowablevertical load (kN)
Weight
(kg/m)
03451
LBGS120-7
4
30
8
03452
LBGS120-9
4.8
22
8

Note: Max output force of manual winch is 5 kN.

Model explanation:
LB X1 X2 - X3
LB : Aluminum alloy gin pole
X1: Stucture
NXG: inner-suspended tubular
NX: inner-suspended lattice
GT: tubular tower mounted
GR: tubular A shape
R: lattice A shape
GX: tubular tripod
X2: for lattice type it is side length, for tubular type it is diameter unit mm
X3: length of the entire gin pole unit: m

How to choose the right model:
1. check in the total capacity required according to the lifting tackle type to be used and the "C" lifting load required.
2. Identify the correct derrick type according to the total capacity, the length and the working position required.
Special design derricks are supplied on demand (e.g.in case of not standard lengths, internal rope passage with special suspended working position attachment etc.)
