Product Details:
Payment & Shipping Terms:
|
| Engine Type: | Gasoline Engine | Engine Model: | Honda |
|---|---|---|---|
| Power: | 5.0HP | Rated Pressure: | 80Mpa |
| Max Oil Pressure: | 94Mpa | Weight: | 55kgs |
| High Light: | 5.0hp hydraulic crimping tool,5.0hp hydraulic electric pump,80Mpa hydraulic electric pump |
||
Application
Application of hydraulic pump: to provide power for the cutting tool, the hydraulic compressor, punching machine
and other construction machinery, which is operated in the wild field in electric power, railway, rescue, construction and other industries.
| Item number | Model | Engine Tyde | Power |
Rated Pressure (Mpa) |
Max Oil Pressure (Mpa) |
Rated Flow (L/min) |
Weight (kg) |
|
| Hig | Low | |||||||
| 16146 | YBQA-80-02 |
Gasoline engine |
5.0HP | 80 | 94 | 1.6 | / | 55 |
| 16147 | YBCA-80-02 |
Diesel engine |
4.0HP | 80 | 94 | 1.6 | / | 65 |
| 16144 | YBDA-80-02 |
Electric engine |
1.5KW | 80 | 94 | 1.6 | / | 45 |
| Item number | Model | Engine Tyde | Power |
Rated Pressure (MPa) |
Max Oil Pressure (MPa) |
Rated Flow (L/min) |
Weight (kg) |
|
| Hig | Low | |||||||
| 16146A | YBQA-80-03 |
Gasoline engine |
5.0HP | 80 | 94 | 2.05 | 11.02 | 55 |
| 16147A | YBCA-80-03 |
Diesel engine |
4.0HP | 80 | 94 | 2.05 | 11.02 | 65 |
| 16144A | YBDA-80-03 |
Electric engine |
3.0KW | 80 | 94 | 1.6 | 8 | 45 |
