Product Details
Place of Origin: NINGBO
Brand Name: NBLK
Certification: ISO CE
Model Number: JJD-30 JJD-50
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 500sets/month
Package Gross Weight: |
108 Kgs, 168kgs |
Gear: |
Four Gear |
Transport Package: |
WOODEN CASE |
Drum Feature: |
Detachable |
Travel Speed(m/min): |
6.5; 8 |
Driven Type: |
Belt |
Traction Force(KN): |
30 Kn 50 Kn |
Power (KW): |
3KW ,4KW |
Package Gross Weight: |
108 Kgs, 168kgs |
Gear: |
Four Gear |
Transport Package: |
WOODEN CASE |
Drum Feature: |
Detachable |
Travel Speed(m/min): |
6.5; 8 |
Driven Type: |
Belt |
Traction Force(KN): |
30 Kn 50 Kn |
Power (KW): |
3KW ,4KW |
The JJD-5 electric motor winch is an advanced piece of machinery that offers exceptional performance and functionality. Equipped with a powerful 4KW motor, clutch, gearbox, brake, and winch roller component, this winch is capable of handling a wide variety of tasks with ease and efficiency.
One of the key benefits of the JJD-5 electric motor winch is its ease of maintenance and operation. Thanks to its advanced design, this machine is simple to maintain, and requires only minor repairs or adjustments with regular use. Additionally, it is designed to be highly intuitive and user-friendly, making it easy for operators of all skill levels to use effectively and safely.
| Item number | Model |
Rotation direction |
Gear |
rotational speed () |
Traction speed (m/min) |
Tractive force (T) |
Power (KW) |
Outline size (mm) |
Weight (kg) |
| 09121 |
JJQ-3Q 6HP Gasoline engine |
corotation |
Ⅰ Slow |
9.0 | 4.0 | 3.0 | 4.04 | 840x450x500 | 82 |
|
Ⅱ Fast |
16.0 | 6.6 | 1.8 | 780x450x500 | 85 | ||||
| reversal | Reverse | 7.5 | 3.3 | No lifting | |||||
| 09121A |
JJC-30 170F Diesel engine |
corotation |
Ⅰ Slow |
11.5 | 5.0 | 3.0 | 2.94 | 840x600x500 | 108 |
|
Ⅱ Fast |
21.0 | 9.0 | 1.8 | ||||||
| reversal | Reverse | 10.0 | 4.5 | No lifting | |||||
| 09121B |
JJD-30 3KW Electromotor |
corotation |
Ⅰ Slow |
8.5 | 4.0 | 3.0 | 3.00 | 770x600x460 | 108 |
|
Ⅱ Fast |
10.5 | 6.5 | 1.8 | ||||||
| reversal | Reverse | 7.0 | 3.0 | No lifting | |||||
| 09123 |
JJQ-50 9HP Gasoline engine |
corotation |
Ⅰ Slow |
6.5 | 4.0 | 5.0 | 6.61 | 1000x550x520 | 135 |
|
Ⅱ Fast |
16.0 | 9.0 | 2.2 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting | |||||
| 09123A |
JJC-50 6.6HP Diesel engine |
corotation |
Ⅰ Slow |
8.0 | 4.5 | 5.0 | 4.41 | 1000x750x600 | 168 |
|
Ⅱ Fast |
19.0 | 11.0 | 2.3 | ||||||
| reversal | Reverse | 10.0 | 5.5 | No lifting | |||||
| 09123B |
JJD-50 4KW Electromotor |
corotation |
Ⅰ Slow |
5.5 | 3.5 | 5.0 | 4.00 | 1000x850x520 | 160 |
|
Ⅱ Fast |
14.0 | 8.0 | 3.0 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting |
Engine: The JJD-5 electric motor winch comes equipped with a 4KW motor. It boasts reliable performance, as well as convenient operation and maintenance.
Transmission and Gear Shift: The winch is powered by the triangle belt transmission to the gear case. The clutch handle controls the winch work. By using the clutch torque, the multistage gear output is sent to the winch roller.
Lubrication: Various parts of the gearbox depend on splash lubrication. Prior to use, three liters of 10# engine oil should be injected into the gear box label position on a new machine. Regular maintenance should include an oil change every six months, or whenever new oil is needed.
The product is characterized by:
The machine is designed to be compact in structure, making it easy to maneuver in different working conditions.
Due to its small volume and light weight, this machine is ideal for use in areas with difficult terrain such as water or mountains.
This machine is simple to operate and reduces the need for field staff, leading to a reduction in labor intensity and an increase in work efficiency.
The interlocking brake on this machine ensures precision positioning and reliable lifting of heavy objects at any location.
The Electric capstan winch is a versatile tool that offers numerous benefits to different sectors. Its design features a reasonable structure that makes it easy to operate. Its reliability and safety also make it an important equipment across various industries.
Its versatility allows it to be widely used in different industries, including electric power transmission, power supply, post and telecommunications engineering, mining, railway, and many others. It can be used for different tasks, such as setting up poles and towers, pulling cables, and handling different loads.
Therefore, Electric capstan winch is an essential tool for many businesses and industries. With its innovative design, it makes work easier and allows businesses to complete tasks more efficiently. It is a tool that companies can rely on to deliver results in the most demanding situations.
If you're looking for a reliable and efficient tool to help simplify your work process, Electric capstan winch is the right choice. Its advantages are significant, and it's a versatile tool that can be used for various purposes.
