30 Kn 4.04 KW Gasoline Engine Cable Pulling Winch With Detachable Drum

Product Description:

The development and design of this CAPSTAN WINCH was undertaken with a great deal of specialization and research. The JJ-5B motor-capstan winch comes with a diverse range of linear velocities, spanning from 4 to 24 meters per minute, and it also includes multi-shift gears. Due to the robustness and efficiency of the product, it is widely used across a range of sectors, such as electricity transmission, telecom, railway, and port infrastructure construction.
The straight shaft link of the power system and gearbox means that it has a compact configuration, making it both safe and reliable. The product has become an essential tool for various tasks, including erecting poles and wires, fastening wires, and hoisting.

Fast powered shaft driven winch data sheet

Features:

The JJ-5B winch is a very useful piece of equipment when it comes to situations where electric sources are not available. It is a traction tool that boasts of small volume and light weight, but at the same time offers great pulling force. The product is particularly suited for use in river-concentrated and mountainous areas.
The winch is made up of a series of components including a gasoline engine, clutch, gearbox and planetary reducer. The gasoline engine provides the necessary power and energy for the machine to operate, while the clutch helps control the speed. The gearbox is responsible for transmitting power from the engine to the machine, while the planetary reducer is responsible for reducing the speed while increasing the torque.
One of the biggest advantages of the JJ-5B winch is its ease of maintenance and operation. This is because the machine has been designed in a way that makes it easy for even novices to use. The machine is also designed in such a way that makes it easy to overhaul should the need arise. Overall, the JJ-5B winch is a vital piece of equipment that is a must-have in areas that are without electric sources.

Technical Parameters:

The JJ-5B type capstan winch uses a Honda 390 gasoline engine, which has a rated power output of 6.6kw. It is started by using a hand rope. The JJC-5B type capstan winch uses an 186F type direct injection diesel engine, with a rated power output of 5.7kw, and is started by a hand crank.
Both the gasoline and diesel engines have a high reputation in China, and they are known for being reliable, easy to maintain and operate.

The clutch passes the movement and power to the synchronous moving fixed seat by the elastic couplet shaft device. The clutch handle rotation promotes the activities wheel and fixed taper surface to contact, and the clutch output the movement and power under the function of friction.
The clutch has the features of good fixed centricity, strong suction vibration ability, great transmitting torque, smooth and flexible operation, and clutch freedom, among other features. In addition, the clutch handle is also equipped with lateral or radial positioning devices to facilitate the operators to work long hours.

The gearbox is directly connected to the engine's movement and power through the clutch. The gearbox adopts cylindrical gear transmission and spline connection straight tooth to shift for meeting the speed that the whole machine requires. The product is, therefore, compact in structure, small in volume, and easy and flexible to operate with sensitive shift.

This machine's braking agency uses a combination that includes the main brake and the hand brake. The main brake adopts the beyond type one-way brake, and it is installed on the output shaft in the gearbox. The hand brake is controlled by the clutch handle; it stops the gearbox’s movement by friction when the clutch withdraws, achieving the braking effect.

This product adopts the involute one tooth differenced planetary reducer(PIC2), which is constituted by partiality axis, inside gear ring, and two upward symmetrically arranged planetary gears and output institution. This reducer has the features like great transmission ratio, compact structure, small volume, light weight, and long service life and so on.

The winch roller uses high-quality steel and connects with the output shaft of the planetary reducer. It adopts a combination of rolling bearings and sliding bearings to achieve an unloading force device. The winch roller uses activities supporting brackets to facilitate loading and unloading of the steel wire rope.

Applications:

The Cable Winch Puller is versatile and can be used in various occasions and scenarios, such as:

• Construction sites
• Landscaping projects
• Off-road adventures
• Farming and agriculture

With a minimum order quantity of 1 and a supply ability of 500 sets per month, you can easily acquire the Cable Winch Puller for your business or personal use. The price is available upon request and a wooden case is included in the packaging for safe transportation. Delivery time is between 3-7 days, and payment terms are T/T.
The Cable Winch Puller by NBLK features a detachable drum and four gears, providing a smooth and efficient operation. With a traction force of 30 KN and 50 KN, this winch puller can handle heavy loads with ease.
Whether you need a 5 ton gas power winch or a petrol engine powered winch, the Cable Winch Puller by NBLK is the perfect solution. It is a gas powered winch that ensures reliable and consistent performance every time. The trademark of NBLK guarantees that the product is of high-quality and dependable.
Invest in the Cable Winch Puller by NBLK for a powerful and efficient tool for all your heavy-duty tasks. Order now and experience the convenience and durability of this winch puller!
