| MODEL: | SHD 250*40 | MATERIAL: | ALUMINUM SHEAVE |
|---|---|---|---|
| RATED LOAD: | 20KN | FEATURE: | LIGHT |
| CONDUCTOR: | LJG150~240 | WEIGHT: | 4.6KG |
| High Light: | transmission line stringing block,stringing pulley block |
||
SHD 20 KN Rated Load Single Aluminum Sheave Stringing Block Conductor Stringing Block
Single sheave stringing block Products:
|
Item number |
Model |
Suitable conductor |
Rated load (kN) |
Weight (kg) |
Remark |
| 10171 | SHD-120×30 | LGJ25～70 | 5 | 1.5 |
Aluminium sheave |
| 10172 | SHD-160×40 | LGJ95～120 | 10 | 2.5 | |
| 10173 | SHD-200×40 | LGJ150～240 | 15 | 4 | |
| 10174 | SHD-200×60 | LGJ150～240 | 15 | 4.6 | |
| 10175 | SHD-250×40 | LGJ150～240 | 20 | 4.6 | |
| 10176 | SHD-250×60 | LGJ300～400 | 20 | 6 | |
| 10177 | SHD-270×60 | LGJ300～400 | 20 | 7 | |
| 10178 | SHD-320×60 | LGJ300～400 | 20 | 9.5 | |
| 10179 | SHD-400×80 | LGJ400～500 | 20 | 15 | |
| 10191 | SHDN-120×30 | LGJ25～70 | 5 | 1.5 |
Nylon sheave |
| 10192 | SHDN-160×40 | LGJ95～120 | 10 | 2.5 | |
| 10193 | SHDN-200×40 | LGJ150～240 | 15 | 3.6 | |
| 10194 | SHDN-200×60 | LGJ150～240 | 15 | 4 | |
| 10195 | SHDN-250×40 | LGJ150～240 | 20 | 4 | |
| 10196 | SHDN-250×60 | LGJ300～400 | 20 | 4.5 | |
| 10197 | SHDN-270×60 | LGJ300～400 | 20 | 5.6 | |
| 10198 | SHDN-320×60 | LGJ300～400 | 20 | 6.7 | |
| 10198-1 | SHDN-320×80 | LGJ300～400 | 20 | 8 | |
| 10199 | SHDN-400×80 | LGJ400～500 | 20 | 13 | |
| 10199-1 | SHDN-400×100 | LGJ400～500 | 20 | 15 | |
| 10199-2 | SHDN-400×120 | LGJ400～500 | 20 | 18 |
Quick Information:
1. transmission line stringing pulley block
2. overhead line stringing tools and accessories
3. Donghuan Brand
4. It has Aluminum material and Nylon material
5. The frame is highly galvanized
Conductor stringing block Configuration:
1.The product is classified as hook style and clevisstyle; 2.More specification can be customized .
