Product Details
Place of Origin: NINGBO CHINA
Brand Name: NBLK
Certification: ISO CE
Model Number: SLE(S) ,SLE
Payment & Shipping Terms
Minimum Order Quantity: 10
Price: Get the latest
Packaging Details: Wooden case packed
Delivery Time: 3-7days
Payment Terms: T/T
Supply Ability: 4000 sets/month
Broken Load (KN): |
Max 75KN |
Name: |
OPGW Socket Pulling Grips |
OPGW Diameter: |
7-22mm, Or Customized |
Packing Type: |
Wooden Case |
Model: |
SLE,SLE(S) |
Appication: |
OPGW Stringing Operations |
Rated Loac: |
10-25KN |
Broken Load (KN): |
Max 75KN |
Name: |
OPGW Socket Pulling Grips |
OPGW Diameter: |
7-22mm, Or Customized |
Packing Type: |
Wooden Case |
Model: |
SLE,SLE(S) |
Appication: |
OPGW Stringing Operations |
Rated Loac: |
10-25KN |
Mesh socket joints are utilized to pull overhead conductors, OPGW cables, earth wires, as well as underground power or telecommunication optic fiber cables. These joints are crafted from durable galvanized steel wire and are tailored to various cable specifications.
The head-type and double head-type temporary mesh sock joints are custom-built for the temporary linkage of aluminum, steel, or copper conductors to the pulling rope.
MESH SOCKET JOINTS FOR OPGW AND EARTH WIRE
| Single head Item No. | Double head Item No. | Model | Cable Diameter (mm) | Load (KN) | |
| With protector | w/ protector | Rated | Break | ||
| 17141 | 17141S | SLE(S)-1 | Φ 7-11 | 10 | 30 |
| 17142 | 17142S | SLE(S)-1.5 | Φ 11-15 | 15 | 45 |
| 17143 | 17143S | SLE(S)-2 | Φ 15-18 | 20 | 60 |
| 17144 | 17144S | SLE(S)-2.5 | Φ 18-22 | 25 | 75 |
The product is made of high-quality steel that has undergone heat treatment and galvanization for a smooth surface finish.
It consists of two ends - one end is a galvanized steel wire rope, while the other end connects to the conductor.
The mesh sock joints are specially crafted for the pulling or installation of OPGW cable or GSW cable during transmission line stringing operations. Fabricated from high-strength galvanized steel wire, these joints are designed with variable pitch steel wires that ensure an effective distribution of gripping force on the OPGW or earth wire.
The Temporary Mesh Sock Joints have a length of 1.2m and are utilized for securing OPGW or Earth Wire. These pulling grips are intricately braided from strands of high-strength galvanized steel wire, enabling them to firmly hold the OPGW cable while safeguarding its surface.
Application: OPGW Socket Joints are designed for gripping Optical Ground Wire (OPGW) or Galvanized Steel Wire (GSW) during line stringing operations. The product is constructed from high-strength galvanized steel wire, allowing it to smoothly pass through stringing blocks and tension wheels.
The Mesh Socket Joints are crafted from high-strength galvanized steel wire that is intricately braided in a soft manner. They are further protected by aluminum and copper sleeves. These sleeves serve the dual purpose of safeguarding the conductor and preventing damage to the Mesh Socket Joints from the OPGW head.
Product Customization Services for the OPGW Installation Tools:
Brand Name: NBLK
Model Number: SLE(S), SLE
Place of Origin: NINGBO CHINA
Certification: ISO CE
Minimum Order Quantity: 10
Price: Get the latest
Packaging Details: Wooden case packed
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 4000 sets/month
OPGW Diameter: 7-22mm, Or Customized
Packing Type: Wooden Case
Model: SLE, SLE(S)
Broken load (KN): Max 75KN
Name: OPGW Socket Pulling Grips
