Product Details
Place of Origin: NINGBO CHINA
Brand Name: NBLK
Certification: ISO CE
Model Number: SLE(S) ,SLE
Payment & Shipping Terms
Minimum Order Quantity: 10
Price: Get the latest
Packaging Details: Wooden case packed
Delivery Time: 3-7days
Payment Terms: T/T
Supply Ability: 4000 sets/month
Appication: |
OPGW Stringing Operations |
Model: |
SLE,SLE(S) |
Packing Type: |
Wooden Case |
Name: |
OPGW Socket Pulling Grips |
Broken Load (KN): |
Max 75KN |
OPGW Diameter: |
7-22mm, Or Customized |
Appication: |
OPGW Stringing Operations |
Model: |
SLE,SLE(S) |
Packing Type: |
Wooden Case |
Name: |
OPGW Socket Pulling Grips |
Broken Load (KN): |
Max 75KN |
OPGW Diameter: |
7-22mm, Or Customized |
Mesh socket joints are utilized for the pulling of overhead conductors, OPGW, and earth wires, as well as underground power cables or telecommunication optic fiber cables. These sockets are constructed from high-strength galvanized steel wire and are tailored to the specifications of various cables.
The head-type and double head-type temporary mesh sock joints are uniquely engineered for the temporary linkage between aluminum-steel or copper conductors and the pulling rope.
The product is constructed using high-grade steel that has undergone heat treatment and galvanizing for surface protection.
It is designed to connect two components: one end features a galvanized steel wire rope, while the other end connects to the conductor.
The mesh sock joints are specifically designed for pulling or installation of OPGW cable or GSW cable in transmission line stringing operation. It is braided from high strength galvanized steel wire. They consist of variable pitch steel wires, which effectively distribute the gripping effect on the OPGW wire or earth wire.
The Temporary Mesh Sock Joints length is 1.2m, it is used to hold OPGW or Earth Wire. The pulling grips are specially braided from high strength galvanized steel wire strands. It can hold the OPGW tightly and protect the surface of OPGW well.
MESH SOCKET JOINTS FOR OPGW AND EARTH WIRE
| Single head Item No. | Double head Item No. | Model | Cable Diameter (mm) | Load (KN) | |
| With protector | w/ protector | Rated | Break | ||
| 17141 | 17141S | SLE(S)-1 | Φ 7-11 | 10 | 30 |
| 17142 | 17142S | SLE(S)-1.5 | Φ 11-15 | 15 | 45 |
| 17143 | 17143S | SLE(S)-2 | Φ 15-18 | 20 | 60 |
| 17144 | 17144S | SLE(S)-2.5 | Φ 18-22 | 25 | 75 |
OPGW Socket Joints are designed for gripping OPGW or GSW during line stringing operations. These products are specially crafted from high-strength galvanized steel wire, ensuring durability and reliability. They are capable of smoothly passing through stringing blocks and tension wheels.
The Mesh Socket Joints are constructed using high-strength galvanized steel wire that is intricately braided in a soft manner. They are further enhanced with protective aluminum sleeves and copper sleeves. These sleeves serve to shield the conductor and prevent the OPGW head from causing damage to the Mesh Socket Joints.
Product Customization Services for the OPGW Installation Tools
Brand Name: NBLK
Model Number: SLE(S) ,SLE
Place of Origin: NINGBO CHINA
Certification: ISO CE
Minimum Order Quantity: 10
Price: Get the latest
Packaging Details: Wooden case packed
Delivery Time: 3-7days
Payment Terms: T/T
Supply Ability: 4000 sets/month
Packing type : Wooden Case
Working load (KN): Max 75KN
Model: SLE,SLE(S)
Name: OPGW Socket Pulling Grips
OPGW Diameter: 7-22mm, Or Customized
