MC Nylon Sheave 660mm Stringing Block For Overhead Line Transmission

MC Nylon Sheave 660mm Stringing Block For Overhead Line Transmission

MC Nylon Sheave 660mm Stringing Block For Overhead Line Transmission

Product Details:

Place of Origin: Ningbo china
Brand Name: Lingsheng
Certification: ISO CE
Model Number: 660 mm

Payment & Shipping Terms:

Minimum Order Quantity: 10sets
Price: get the latest
Packaging Details: std exported packing
Delivery Time: 3-5 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 3000sets/month
Contact Now
Detailed Product Description
Model: 660 MM Stringing Block Sheave: 1,3,5
Rated Load: 60KN Weight: 150kg
Material: MC Nylon Sheave Item: Stringing Block



660mm Stringing Block for Paying off the Max ACSR 500 Condutor in Overhead Line Transmission



660mm Stringing Block

Usage: Protect the cable and conductor from fricting when they are laying.They can save time and effort.

1.Maximum suitable conductor ACSR500

2.Sheave dimension( outside diameter× rootdiameter × sheave width) Φ660×Φ560×100(mm)

3.Sheave dimension Φ660×Φ560×110(mm) can be customized.



Apply to paying off single conductor, twin bundled conductor or four bundled conductor on overhead transmission line construction.

Specification: Product can be made of aluminum wheel with rubber liner, MC nylon wheel with rubber liner or strengther nylon wheel with PU liner

Technical Data

Item number Model Number of sheaves Rated load (kN) Weight (kg) Features
10121 SHD660 1 20 30 Rubber lined aluminium sheave
10122 SHS660 3 40 100

Middle : Cast steel sheave

Conductor : Rubber lined aluminium sheave

10123 SHW660 5 60 150
10124/10124A SHDN660 1 20 26 MC nylon sheave
10125 SHSLN660 3 40 86

Middle : MC nylon sheave

Conductor : Rubber lined aluminium sheave

10126 SHWLN660 5 60 120
10127/10127A SHSQN660 3 40 70 MC nylon sheave
10128/10128A SHWQN660 5 60 110
10130 SHQ660A 7 75 190

Middle :cast steel sheave

Conductor : MC nylon sheave

MC Nylon Sheave 660mm Stringing Block For Overhead Line Transmission
